1、Model：TB256V-A.B.C
Picth：A=5.08mm(.200")/7.62mm(.300")
Poles QTY：2P-25P
Color：black（can choice）
2、Dimensioned drawing：
PCB hole size: ø1.4*5.08/7.62mm
3、BOM：
|
No. |
ITEM |
Origin |
Material |
Surface |
QTY |
|
1 |
Housing |
Own making
|
PC |
—— |
1 |
|
2 |
Pin header |
Own making |
Brass |
Tin Plated |
2-25 |
4、Technical data：
Voltage&Current：250V 12A
Withstanding Voltage：AC2500V 60s
5、Environment：
Operating Temperature：-40℃ ~ +105℃
Pollution Level：Ⅲ
6、Inspection standards：
GBT 2828.1-2012
7、Useing：
Soldering：
Wave Soldering：260℃/5s
Hand Soldering：soldering iron350℃/10s
